- Simple Setting and Installation
To go to Setting Menu, touch the Time, Pressure, and Temperature area. Make settings with the use of the Up/Down button on the right. - Wide Entry Door
Wide entry for easy entrance - One-Touch Therapy Mode
With the use of five therapy protocols built in program, it is possible to set up a therapy mode for a patient simply. - All-in-One Internal Display
The display integrated with interphone is applied. Therefore, any unnecessary receiver is removed, and more convenient communication is supported. In addition, it is possible to control pressure, time, and temperature inside. - Liquefied Oxygen Connectable
It is possible to connect liquefied oxygen instead of oxygen generator. (If necessary) - Emergency Pressure Reset Valve
Emergency valve installed for decompression intuitively
SPECIFICATION
Model O₂ FRESH-M50 O₂ FRESH-M50 plus Usage One patient One patient Operation Pressure 10 ~ 50kPa (1.1~1.5ATA) 10 ~ 50kPa (1.1~1.5ATA) Size 2200 x 800mm 2200 x 920mm Weight 125kg 150kg Material Aluminum AluminumFlow Rate 100L / Min Voltage 220/110VAC, 50/60Hz Power Consumption 950VA Size 94Kg Weight 94Kg Material Steel
Oxygen Flow Rate 1~5L / Min Oxygen Concentration 93% ± 3% Voltage 220VAC, 50/60Hz Power Consumption 270W Noise Less than 45db Size 400(W) x 300(D) x 510(H)mm Weight 16.5kg
